Ceramic Digital Printer

Mini Jet Digital Printer

Mini jet is developed specifically for wall tile production line. It is very cmpact with full-featured.
The up-to-date double belt has been designed according to innovative criteria,
there will not affect the glaze line production any more during the machine’s maintenance or sample testing etc.
It’s equipped with the same XAAR print heads, mature ink system and print system with King jet’s
 so as to provide more and better choice for customer because of high quality and more economic price.


Model And Technical Parameter
Model code M:Mini Jet The height from the belt surface to the ground 1100+/- 50mm
Color bar 6 Weight 1600KG
Printhead for choice GS6/GS12/GS40,SG600-SC Installed power 12- 14.2KW
Printing resolution XAAR:360dpi.720dpi,StarFire : 400dpi.600dpi Overall dimension 3430X170X1250
